DuPont Selar® PA 3426 Nylon Barrier Resin

[2019-04-29 08:57:42]

DuPont Selar® PA 3426 Nylon Barrier Resin

Polymer,Thermoplastic,Nylon,Nylon, Barrier Film Copolymer

DuPont Packaging and Industrial Polymers

产品说明:

Selar® PA 3426 is an amorphous nylon (polyamide) resin which exhibits superior transparency, good barrier properties to gases, water, solvents and essential oils and high temperature structural properties which make it suitable for consideration in a number of packaging applications. It can be processed on conventional extrusion and injection equipment designed to process nylon ｏｒ polyolefin resins. It is available in the form of small, free flowing pellets in 25 kg (55 lb.) foil-lined bags ｏｒ 750 kg. (1653 lb.) foil lined boxes.

Information provided by DuPont Packaging Polymers.

DuPont Selar® PA 3426 Nylon Barrier Resin 物性表

物理性能	额定值 (公制)	额定值 (英制)	测试方法
密度	1.19 g/cc	0.0430 lb/in³	ASTM D1505
Oxygen Transmission	0.470 cc-mm/m²-24hr-atm	1.19 cc-mil/100 in²-24hr-atm	40% RH, 23°C
粘度	200000 cP @Shear Rate 100 1/s, Temperature 300 °C	200000 cP @Shear Rate 100 1/s, Temperature 572 °F

机械性能	额定值 (公制)	额定值 (英制)	测试方法
弯曲模量	2.80 GPa	406 ksi	at 50% RH; ASTM D790

热性能	额定值 (公制)	额定值 (英制)	测试方法
载荷下热变形温度(0.46 MPa)	126 °C	259 °F	ASTM D648
载荷下热变形温度(1.8 MPa)	123 °C	253 °F	ASTM D648
玻璃化转变温度，Tg	127 °C	261 °F	ASTM D3418

加工性能	额定值 (公制)	额定值 (英制)	测试方法
加工温度	280 - 320 °C	536 - 608 °F	Recommended for injection molding.
